KTM Macina Aera FS Elite LFC US
The KTM Macina Aera FS Elite LFC 2026 is a full-suspension trekking e-bike that blends comfort, performance, and everyday functionality. With a carbon frame, powerful Bosch Performance CX motor (100Nm), 800Wh Bosch PowerTube battery, and intuitive Bosch Kiox500 display, it’s built for effortless long rides. The Suntour XCR Air fork (100mm travel), Shimano CUES (1×11) drivetrain, hydraulic brakes, and full LFC equipment—light, fenders, and rack—make it an ideal companion for both urban commutes and off-road adventures.
Highlights
Lighting
Litemove SEC-150
Frame
Carbon
Fork
Suntour XCR34 Air (100mm)
Shifter
Shimano CUES (1x11)
Brakes
Shimano MT402/MT420 (203/180)
Drive Unit
Bosch Perf. CX (100Nm) / PowerTube (800Wh)
KTM Macina Aera FS Elite LFC - comfort meets versatility
The KTM Macina Aera FS Elite LFC is a comfortable step-through bike with full suspension that is ideal for the city and long, relaxed rides across country. Thanks to the powerful Bosch Performance Line CX motor with 800 Wh PowerTube battery, every ride is effortless and long-lasting. The full-suspension chassis ensures a smooth, comfortable ride, regardless of the surface. Perfect for anyone who values comfort and riding enjoyment without having to sacrifice performance.
Equipped with a Shimano CUES 11-speed drivetrain, the Aera FS Elite offers precise and smooth gear changes, while the powerful Shimano MT420 4-piston disc brakes ensure reliable braking power and safety. The low entry makes it easier to get on and off the bike and makes it particularly user-friendly. With robust components and well thought-out equipment, including lights and mudguards, the Macina Aera FS Elite LFC is the ideal companion for everyday use and relaxed tours.
Bosch update July 2025: Are you ready for more power?
From July 2025, you can increase the torque of the Gen 5 Bosch motors (BDU38) to up to 100 Nm using the Flow app. Your advantage: noticeably more thrust and up to 400% motor support. You can use the eBike Flow app to customise the riding modes and adapt the performance precisely to your riding style.
Bosch Performance CX – redefining e-biking!
The new Bosch Performance Line CX motor offers everything you need for your e-mountain bike experience: power, handling and quiet operation. With up to 100 Nm of torque, it provides powerful support on steep climbs and challenging trails. Thanks to improved sensor technology, the motor responds even faster to your pedalling and ensures a dynamic, natural riding experience. Weighing just 2.8 kg, the motor noticeably improves the handling of your e-bike, which really pays off on long tours and technical sections. It also runs more quietly, making for a more pleasant riding experience. Features such as Extended Boost and the revised push assist give you maximum control off-road. With these new features, the Bosch Performance Line CX motor takes your e-mountain bike experience to a whole new level.
Additional Information
| General | |
| Bike category | E-MTB Full Suspension |
|---|---|
| Model year | 2026 |
| Colour | Olive Pearl Matt (Black+Orange) |
| Weight | 29,1 kg |
| Fahrraddetails | |
| Price | Price in branch store might be lower. (info@rabe-bike.de / +4989 125 01 01 01) |
| Frame | |
| Frame | Macina Aera Carbon 100 UDH|PT800 Bosch BDU38/T5880 |
| Fork | Suntour XCR34 Air 27.5" LOR 100mm 15x110 |
| Rear Shocks | Suntour EDGE-EVO 2CR 190x45 |
| Headset | Acros AICR internal 1.5"-1.5" |
| Frame type | Fully |
| Drive | |
| Shifters | Shimano CUES U6000-11 display |
| Rear derailleur | Shimano CUES U6000-11/10 LG shadow+ |
| Crank | KTM E-COMP2 ISIS 170mm Q8 |
| Chain rings | Miranda steel 38T Direct Mount |
| Cassette | Shimano LG400-11 / 11-50 |
| Chain | Shimano LG500 |
| Ebike | |
| Battery pack | Bosch PowerTUBE 800Wh horizontal |
| E-Engine | Bosch PERFORMANCE CX BDU3840 |
| Display | Bosch KIOX 500 TFT Display |
| Charger | Bosch STANDARD Charger 4A |
| Brakes | |
| Brake | Shimano MT402 (3-F) / MT420 4-Piston, Shimano RT30 CL 203, Shimano EM300 CL 180 magnet |
| Brake lever | Shimano MT500 SP-Lever |
| Wheels | |
| Rims | Ryde Rival30 32H 584/622x30C |
| Front tire | 27,5": Schwalbe Johnny Watts Perf. Folding DD 65-584 Reflex, 29": Schwalbe Johnny Watts Perf. DD Raceguard 60-622 Reflex |
| Rear tire | 27,5": Schwalbe Johnny Watts Perf. Folding DD 65-584 Reflex, 29": Schwalbe Johnny Watts Perf. DD Raceguard 60-622 Reflex |
| Wheel Size | 27,5'' |
| Front hub | Shimano TC500B CL 32H 110-15TA |
| Rear hub | Shimano TC600B CL 32H 148-12TA |
| Cockpit | |
| Handlebar | KTM TEAM II rizer15 700mm |
| Stem | KTM Line adjust. 0-60° ICR |
| Grips | GRIP ERGON GP10 |
| Seat | |
| Saddle | Selle Royal Lookin Evo |
| Seatpost | KTM Line II dropper 30.9 T:100 |
| Saddle clamp | KTM Line JD-SC140A - 35,0mm |
| Light | |
| Headlight | Litemove SEC-150 150Lux CT1 connector |
| Acessory | |
| Mudguards | Racktime Alu 72mm |
| Rack | KTM light 42 snap-it 2.0/monkeyload|rack clip |
| Bike stand | KTM 28" adjustable MY2025 |
| Other | |
| Further details | Size Split: 27.5: 40cm // 29: 46cm, 51cm, 56cm |
| Customization - only in store | |
| Configuration - available in our stores | |
| Annotation | The illustration may differ. The manufacturer reserves the right to replace certain components with components of equivalent quality. |
| Manufacturer Information | |
| Manufacturer Information | KTM Fahrrad GmbH |
| Product Safety Documents | |
