Orbea Wild H20

Item no. 79426
6,499.00 € *
[1]
Size
Ready for any adventure? The Wild H20 with aluminium frame offers you everything you need for demanding trails: a powerful mix of RockShox and FOX suspension as well as precise Shimano SLX/Deore 12-speed gearing. Powered by the Bosch Performance CX Smart System and a 750 Wh battery, you can master even the steepest climbs and technical descents with ease.

Highlights

Frame

Aluminium

Fork

RockShox ZEB (170mm)

Shifter

Shimano Deore/SLX (1x12)

Brakes

Shimano MT420 (203/203)

Rear Shock

Fox Float X Performance

Drive Unit

Bosch Perf. CX (100Nm) / PowerTube (750Wh)

Orbea Wild H20 - The high-performance model in the Wild aluminium series

The E-Fullys from the Orbea Wild series are the ticket for your trail adventures with a high downhill factor. The Enduro class in particular benefits noticeably from E-support. You can finally reach your favourite trails and descents without exhausting yourself to the point of total exhaustion. A chassis with 160 millimetres of suspension travel has its weight. When developing the Wild, however, Orbea took care to save weight at every sensible point. Quite simply to maximise the performance and endurance of the Bosch Performance CX motor and the 750 Wh battery. And we succeeded! The Wild models are among the lightest e-enduro bikes on the market. The enduro bikes were developed in collaboration with the Orbea race team. Agile handling is a decisive factor in races.

There are two series of the Wild: The M models with carbon frames and the more affordable H models with aluminium frames. In the H20 version, the Wild comes with a high-quality combination of RockShox Zeb suspension and Fox Float X Performance shock. These components are characterised by minimal friction at the seals and a perfect setup. The wide-range combination of Shimano SLX and Deore components masters even the steepest climbs. The service-friendly Deore disc brakes also come from Shimano. Thanks to 4-piston technology, they deliver high braking power even with low manual force. And in typical Orbea fashion, a telescopic seatpost is also included as standard, so you can hit the trails straight away.

Bosch Performance CX - redefining e-biking!

The new Bosch Performance Line CX motor offers everything for your e-mountainbike experience: power, handling and quiet operation: with 100 Nm torque, it provides powerful support on steep climbs and challenging trails. Thanks to improved sensor technology, the motor reacts even faster to your pedalling and ensures a dynamic, natural riding experience. Weighing just 2.8 kg, the motor noticeably improves the handling of your e-bike, which is particularly beneficial on long tours and technical passages. It also works more quietly, making for a more pleasant riding experience. Features such as the Extended Boost and the revised push assist give you maximum control off-road. With these new features, the Bosch Performance Line CX motor takes your e-mountainbike experience to a whole new level.

Orbea - high-quality bicycles from Spain

Founded back in 1840 as an armoury, Orbea has been one of the most important traditional manufacturers of bicycles in Spain since the 1930s. Based in the bike-mad Basque Country, the company's philosophy has always been to be close to the sport. Fans know the legendary atmosphere on the roads when the Tour de France makes a detour into the Spanish Pyrenees. Numerous professional MTB and road cycling teams rely on the quality of bikes from the Basque Country.

Additional Information

General
Bike category E-MTB Full Suspension
Model year 2025
Colour Spaceship Green - Black
Frame
Frame Orbea Wild Hydro, 29" wheels, Concentric Boost 12x148
Fork RockShox ZEB Base-A2 DebonAir+ 170 E-MTB specific 15X110 Boost
Rear Shocks Fox Float X Performance Trunnion 2-Pos Evol LV custom tune 205x65mm
Headset Alloy 1-1/2", Black Oxidated Bearing
Frame type Fully
Drive
Shifters Shimano Deore M6100 I-Spec EV
Rear derailleur Shimano SLX M7100 SGS Shadow Plus
Chain guide e*thirteen Plus Bosch CX Gen4 CL 55 32-36t
Crank e*thirteen Helix Core
Chain rings e*thirteen e*spec Direct Mount 34T Boost
Cassette Shimano CS-M7100 10-51t 12-Speed
Chain Shimano M6100
Ebike
Battery pack Bosch Powertube 750Wh Horizontal BBP3770
E-Engine Bosch Performance Line CX BDU3843
Remote Bosch Mini Remote BRC3300
Display Bosch System Controller BRC3100
Charger Bosch Charger 4A (230V) BPC3400
Brakes
Brake Shimano MT420 Hydraulic Disc, Galfer Wave Rotors 203mm front / 203mm rear
Wheels
Wheel set Race Face AR 30c Tubeless Ready
Front tire Maxxis Assegai 2.50" 60TPI 3CG/EXO+/TR MaxxGrip
Rear tire Maxxis Minion 2.40" 120 TPI 3CT/DD/TR MaxxTerra
Wheel Size 29''
Cockpit
Handlebar OC Mountain Control MC30, Rise20, Width 800
Stem OC Mountain Control MC20, 0º
Grips OC Lock On
Seat
Saddle Selle Royal Vivo Sport Men 145 x 269mm
Seatpost OC Mountain Control MC22, 31.6mm, Dropper, Shimano SL-MT500 I-Spec EV
Other
Customization - only in store
Configuration - available in our stores
Annotation The illustration may differ. The manufacturer reserves the right to replace certain components with components of equivalent quality.
