KTM Macina Style FS Prime Di2 US

Item no. 81740
6,299.00 € *
[1]
Size
The KTM Macina Style FS Prime Di2 2026 is a full-suspension premium trekking e-bike with a carbon frame, Bosch Performance CX motor, 800 Wh battery, Suntour suspension and wireless Shimano CUES Di2. High-quality lighting and everyday equipment make it a comfortable ready-to-ride solution.

Highlights

Lighting

B&M IQ-XM 120-170 HighBeam

Frame

Carbon

Fork

Suntour XCR34 Air (100mm)

Shifter

Shimano CUES Di2 (1x11)

Brakes

Shimano MT402/MT420 (180/180)

Drive Unit

Bosch Perf. CX (100Nm) / PowerTube (800Wh)

KTM Macina Style FS Prime Di2 US - comfort and versatility for every use

The KTM Macina Style FS Prime Di2 US is a versatile step-through bike with full suspension that is not only ideal for city rides, but also for comfortable, long trips across country.Equipped with a Suntour XCR34 Air suspension fork, which offers 100 mm of travel, this bike ensures optimum comfort on any terrain so that you can also ride relaxed on uneven roads.

In addition, the Shimano Cues Di2 11-speed drivetrain enables precise and effortless gear changes, while the powerful Shimano MT420 4-piston disc brakes provide safe braking power and give you the confidence you need. A free software update will soon be available that will add an automatic function to the gears, further improving the riding experience and making it even more comfortable.

In addition, the bike is equipped with high-quality B&M IQ-XM lighting, which offers a brightness of 120 to 170 lux and has a practical high beam function. This ensures that you are safe on the road even in poor light conditions. The Schwalbe Green Marathon tyres offer excellent grip and stability, ideal for long distances and city rides.

Bosch update July 2025: Are you ready for more power?

From July 2025, you can increase the torque of the Gen 5 Bosch motors (BDU38) to up to 100 Nm using the Flow app. Your advantage: noticeably more thrust and up to 400% motor support. You can use the eBike Flow app to customise the riding modes and adapt the performance precisely to your riding style.

Bosch Performance CX - redefining e-biking!

  • Powerful motor: The Bosch Performance Line CX motor offers 85 Nm torque (default setting).
  • Optimum support: Ideal for steep climbs and long uphill sections.
  • Fast response: Improved sensor technology ensures a dynamic and natural riding experience.
  • Lightweight: At just 2.8 kg, the motor improves the handling of the e-mountainbike.
  • Quiet operation: Quiet operation of the motor for a particularly pleasant ride.
  • Revised modes:
    • Extended Boost helps to overcome obstacles.
    • Improved push assistance offers more control in difficult terrain.

Additional Information

General
Bike category Trekking E-Bike
Model year 2026
Colour Machine Grey Matt (Silver+Black)
Weight 29,9 kg
Fahrraddetails
Price Price in branch store might be lower. (info@rabe-bike.de / +4989 125 01 01 01)
Frame
Frame Macina Style Carbon 100 UDH|PT800 Bosch BDU38/T5880
Fork Suntour XCM34 Air 27,5" LOR 100mm 15x110
Rear Shocks Suntour EDGE-EVO 2CR 190x45
Headset Acros AICR internal 1.5"-1.5"
Frame type Easy Entry
Drive
Shifters Shimano CUES Di2 EN605 Switch
Rear derailleur Shimano CUES Di2 U8050-11 SGS shadow
Crank KTM E-TEAM2 ISIS 170mm Q8
Chain rings Miranda steel 42T Direct Mount
Cassette Shimano LG400-11 / 11-50
Chain Shimano LG500
Ebike
Battery pack Bosch PowerTUBE 800Wh horizontal
E-Engine Bosch PERFORMANCE CX BDU3840 + Bosch ConnectModule for BDU38YY
Display Bosch KIOX 500 TFT Display
Charger Bosch STANDARD Charger 4A
Brakes
Brake Shimano MT402 (3-F) / MT420 4-Piston, Shimano RT64 CL 180, Shimano EM600 CL 180 magnet
Brake lever Shimano MT500 SP-Lever
Wheels
Wheel set Ambrosio Sport 25 584 32H 584/622x25C
Front hub Shimano TC500B CL 32H 110-15TA
Rear hub Shimano TC600B CL 32H 148-12TA
Tires Schwalbe Green Marathon Perf. GreenGuard 55-584/50-622
Wheel Size 27,5''
Cockpit
Handlebar KTM TEAM II rizer15 700mm
Stem KTM Line adjust. 0-60° ICR
Grips Ergon GP30
Seat
Saddle Selle Royal Lookin Evo
Seatpost KTM Line II dropper 30.9 T:100
Saddle clamp KTM Line JD-SC140A - 35,0mm
Light
Headlight B&M IQ-XM 120-170Lux HighBeam
Back light B&M Toplight 2C
Acessory
Mudguards SKS A65R PET Trek 27,5"
Rack KTM light 42 snap-it 2.0/monkeyload|rack clip
Bike stand KTM 28" adjustable MY2025
Other
Further details

Size Split: 27.5: 43cm // 29: 46cm, 51cm, 56cm

Customization - only in store
Configuration - available in our stores
Annotation The illustration may differ. The manufacturer reserves the right to replace certain components with components of equivalent quality.
