Carbon
FOX 36 Float (160mm)
Shimano Deore XT (1x12)
Shimano Deore XT (203/180)
FOX Float X Performance
Bosch Perf. CX Gen4 (85Nm) / PowerTube (750Wh)
Just the thought of the view from the top of the mountain and the subsequent descent into the valley makes you tingle? Then you should definitely get yourself a Macina Kapoho e-bike Fully. With 160 mm of suspension travel, the Kapoho models are the perfect all-rounders for all conditions. In this case with a carbon frame, all models are equipped with the proven Mullet tyres: 29" wheels at the front for optimal riding stability and steering precision, paired with 27.5" PLUS tyres at the rear for best power transmission and traction, play out their advantages to the full in tough terrain. The heart of the Kapoho line is the frame in combination with the proven STRAIGHT-LINE-LINK (SLL) concept. Not only the powerful motor but also the Shimano XT gears provide the right momentum uphill. The 10-51t 12-speed Deore cassette will take you to (almost) every summit. Downhill, the Maxxis Minion DHF and DHR II tyres provide optimal traction and work in combination with the Shimano XT 4-piston brake for a perfect and safe mountain and trailer experience.
One of the most successful model series of recent years is once again making history. The technically demanding recipe for success sounds quite simple: quality, comfort, performance and stability at the highest level. The Kapoho models remain true to this principle. In combination with the new Bosch Smart System. With this self-contained Bosch system, easily recognisable by the new control unit, you are equipped for the digital future. The long-lasting 750 watt-hour battery delivers its energy to the 4th generation Bosch Performance CX motor. You will hardly find a more powerful and better motor at the moment. The new Bosch Kiox 300 display is also state-of-the-art. Here, too, Bosch has come up with something special. The Kiox 300 display can be freely configured via the Bosch eBike Flow app and software updates for your e-bike can now be carried out from the comfort of your own home. Control of the assistance levels is also possible for owners of a Kiox display. The PowerTube battery is elegantly hidden in the down tube and with its increased 750 watt-hour capacity, it will take you to even the most distant destinations.
Bike category | E-MTB Full Suspension |
---|---|
Brand | KTM |
Model year | 2023, 2024 |
Colour | Flaming Black (Orange) |
Weight | 25,3 kg |
Customization - only in store | |
Configuration - available in our stores | |
Frame | Macina Kapoho Dimmix Perf. Carbon SLL-LTE 160mm UDH; PT750 Bosch Gen.4 / M-2246 |
Frame type | Fully |
Fork | FOX 36 Float 29" Performance e-bike 160mm 15x110 |
Rear Shocks | FOX Float X Performance 2-Pos 250x70 |
Wheel Size | 27,5+, 29'' |
Front tire | Maxxis Minion DHF 3C-MaxxTerra/EXO/TR 63-622 |
Rear tire | Maxxis Minion DHR II 3C-MaxxTerra/EXO/TR 70-584 |
Rims | Ambrosio E35 Trail 32H 584x35TC |
Rear derailleur | Shimano Deore XT M8100-12 SGS shadow+ |
Shifters | Shimano Deore XT M8100-12 |
Crank | KTM E-TRAIL ISIS 160mm Q16 |
Chain rings | FSA Megatooth steel 36T 12speed Direct Mount |
Cassette | Shimano Deore M6100-12 / 10-51 |
Chain | Shimano M6100-12 |
Front hub | DT Swiss 370 CL 28L 110/15 |
Rear hub | DT Swiss 370 CL 28L 148/12 12SP LN18 |
Brake | Shimano Deore XT M8100 / M8120 4-Piston, Shimano MT800 CL 203 / 180 Freeza |
E-Engine | Bosch PERFORMANCE CX Gen.4 SMART SYSTEM - 25km/h / 85Nm |
Battery pack | Bosch PowerTUBE 750Wh SMART SYSTEM hor. |
Display | Bosch LED remote SMART SYSTEM / Bosch KIOX 300 TFT Display SMART SYSTEM |
Charger | Bosch STANDARD Charger 4A SMART SYSTEM |
Handlebar | KTM Team Trail35 rizer25 800mm |
Grips | Ergon GA20 |
Stem | KTM TEAM II Trail35 |
Headset | Acros AICR internal 1.1/8"-1.5" angle limit |
Saddle | Selle San Marco Ground Short Open Fit Narrow |
Seatpost | KTM COMP II dropper internal |
Saddle clamp | KTM Line JD-SC140A - 35,0mm |
Annotation | Illustrations and specifications may vary. The manufacturer reserves the right to replace certain components with components of similar quality. |
