Merida eOne-Sixty 975 (2023)
It’s in the genes. By combining the award-winning handling and mixed wheel size setup with a tough but sleek all-aluminium frame, the eONE-SIXTY 975 delivers stunning value and stunning performance. The refined Shimano EP8 drive unit is powered by a huge 750 Wh battery that’s neatly integrated into the frame. Add in the proven performance of RockShox suspension and the mega-durable Shimano LinkGlide transmission and you’re ready to rock.
Highlights
-
Frame
Aluminium
-
Fork
Rock Shox ZEB Ultimate Air (160 mm)
-
Shifter
Shimano XT RDM8130 Shadow+ (1x11)
-
Brakes
Shimano XT (203/203)
-
Rear Shock
Rock Shox Super Deluxe Select+
-
Drive Unit
Shimano EP8 (85Nm) / Simplo (750Wh)
Merida eOne-Sixty 975
It’s in the genes. By combining the award-winning handling and mixed wheel size setup with a tough but sleek all-aluminium frame, the eONE-SIXTY 975 delivers stunning value and stunning performance. The refined Shimano EP8 drive unit is powered by a huge 750 Wh battery that’s neatly integrated into the frame. Add in the proven performance of RockShox suspension and the mega-durable Shimano LinkGlide transmission and you’re ready to rock.
Additional Information
| General | |
| Bike category | E-MTB Full Suspension |
|---|---|
| Colour | black/silver |
| Max. total weight | 140 kg |
| Frame | |
| Frame | eONE-SIXTY LITE III, aluminium, 150mm suspension travel, 27.5x2.8" max. wheelsize, 148x12mm axle standard |
| Fork | Rock Shox ZEB Ultimate, Air, 160mm suspension travel, Tapered, 51mm fork offset, 29x2.8" max wheelsize |
| Rear Shocks | Rock Shox Super Deluxe Select+ |
| Headset | MERIDA 8152 |
| Frame type | Diamond |
| Drive | |
| Shifters | Shimano SL -MT500-IL / Shimano XT M8130 |
| Rear derailleur | Shimano XT RDM8130 Shadow+ 11 |
| Crank | Shimano FCEM600, 165 mm |
| Chain rings | Shimano CRE80-B 34 teeth |
| Cassette | Shimano LG600, 11-50 teeth, 11 speed |
| Chain | LG500 |
| Ebike | |
| Battery pack | Simplo Internal Battery, 750 Wh |
| E-Engine | Shimano EP8, 85Nm |
| Display | Shimano SC-EM800 |
| Brakes | |
| Brake | Shimano XT, 4 pistons, Shimano RT-MT900 / Shimano RT-EM910 (203 mm/203 mm) |
| Wheels | |
| Rims | MERIDA EXPERT TR, 29mm inner width, aluminium, Tubeless ready (tubeless tape and valves not included) |
| Front tire | Maxxis Assegai, 29x2.5 ", fold, TR EXO+ 3C MaxxGrip |
| Rear tire | Maxxis DHR II, 27.5x2.6 ", fold, 3C EXO+ TR |
| Wheel Size | 27,5+, 29'' |
| Front hub | Shimano XT, 110x15mm width front hub, 32 spoke holes, Centerlock |
| Rear hub | Shimano XT, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Cockpit | |
| Handlebar | MERIDA EXPERT eTR, 780mm width, 20mm rise |
| Stem | MERIDA EXPERT eTRII, aluminium, 35mm diameter, 0° stem angle, GoPro & Supernova mount, 40 mm |
| Grips | MERIDA EXPERT EC |
| Seat | |
| Saddle | MERIDA EXPERT CC, V-mount, incl. MERIDA minitool |
| Seatpost | MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, XS 100mm travel seatpost - S 125mm travel seatpost - M 150mm travel seatpost - L/XL 170mm travel seatpost |
| Saddle clamp | MERIDA EXPERT |
| Light | |
| Headlight | Lezyne E-Bike Power E115, StVZO, reverse MERIDA Custom Mount |
| Back light | Lezyne LED Femto USB, StVZO |
| Other | |
| Customization - only in store | Anpassen der optimalen Sitzposition entsprechend deiner Anatomie |
| Configuration - available in our stores | Individuelles Fahrwerks Setup durch geschulte Mitarbeiter |
| Annotation | Illustrations and specifications may vary. The manufacturer reserves the right to replace certain components with components of similar quality. |
| Manufacturer Information | |
| Manufacturer Information | MERIDA & CENTURION Germany GmbH |
