Carbon
DVO Diamond E3 (160 mm)
SRAM NX/SX Eagle (1x12)
SRAM GUIDE T 4-Piston (203/203)
RockShox Deluxe Select
Bosch Perf. CX Gen4 (85 Nm) / PowerTube (625 Wh)
Ride tours and enjoy the scenery. But also like to branch off on a trail and master technical challenges. Versatility is a decisive purchase argument for you? The Focus Jam² models meet exactly this profile. A full-suspension all-mountain and trail bike with powerful electric assistance. With 150-millimeter suspension, it positions itself in the Focus range between the cross-country-oriented Thron² and the Sam² Enduro. The brand new Jam² 8 Series models are based on a carbon frame with aluminum rear triangle. The material carbon saves weight and makes this all-rounder light and agile in handling. In addition, the frame geometry offers a high freedom of movement thanks to the low projection height. An advantage on winding trails with many changes of direction. The Jam² 8 Series is equipped with the proven Bosch Performance CX motor of the 4th generation, which is powered by a 625 watt-hour battery. So enough energy to rock your favorite trails as many times in a row as you want. In the 8.7 version, the Jam² comes with Sram SX Eagle 1 x 12 gears and broadband touring transmission. The chassis is composed of a RockShox Select DeLuxe shock and a DVO Diamond E3 suspension fork, which is particularly stable thanks to the large overlap of stand and dip tubes. In addition, it offers with 160 millimeters of travel welcome reserves on blocked trails. In this situation, one is also happy about the telescopic seatpost mounted as standard.
With its organic shapes, the Jam² 8.7's main frame takes advantage of carbon. There is no other construction method with which stiffness and power flow can be better controlled. To protect against stone chips, a protector is applied to the down tube in front of the engine block. The F.O.L.D. kinematics developed by Focus ensures that the rear suspension works sensitively over the most used range and only hardens when the suspension is compressed sharply. This protects the frame from damage. The effect: the F.O.L.D. chassis glides sensitively over root trails and gravel roads, but still offers enough reserves at large obstacles.Another special feature is the Bosch System Controller built into the front of the top tube, which in combination with the Bosch Mini Remote on the handlebars takes over the drive control. Minimalism in its most beautiful form.
Bike category | E-MTB Full Suspension |
---|---|
Brand | Focus |
Model year | 2023 |
Colour | Carbon Raw / Blue Green |
Customization - only in store | |
Configuration - available in our stores | |
Frame | Carbon front triangle, aluminium rear triangle, 150 mm F.O.L.D. GEN2 kinematics, 148x12 mm thru axle, internal cable routing, post mount 203 mm |
Frame type | Fully |
Fork | DVO Diamond E3, 110x15 mm, 44 mm rake (160 mm) |
Rear Shocks | RockShox Deluxe Select, 210/55 mm, hardware: 25.0 x 25.0 mm / Federweg Rahmen: 150 mm |
Wheel Size | 29'' |
Tires | Maxxis Minion DHF, 2.6 Dual EXO TR, 66-622, 29x2.6 |
Rims | RaceFace AR30 Offset |
Rear derailleur | SRAM NX Eagle, 12-speed |
Shifters | SRAM SX Eagle, 12-speed |
Crank | Samox EC40 ISIS, 165mm |
Chain rings | front: 36, rear: 11-50 |
Cassette | SRAM PG-1230 Eagle, 12-speed |
Chain | SRAM SX Eagle, 12-speed |
Front hub | Novatec D041, 15x110 mm thru axle |
Rear hub | Novatec D462, 12x148 mm |
Brake | SRAM GUIDE T, 4 Piston (203/203) |
E-Engine | Bosch Performance CX Gen4, 85 Nm, 250 W |
Battery pack | BoschPowerTube (625 Wh), Li-Ion, Downtube, integrated, 36 V, 17,4 Ah |
Remote | Bosch System Controller + Mini Remote |
Handlebar | Aluminium, 800 mm, rise: 30 mm, backsweep: 9° |
Stem | FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium |
Headset | ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated, 1.5/1.8“ angle headset |
Saddle | Selle Royal Groove |
Seatpost | Post Moderne dropper post PM-214, 34.9 mm |
Max. total weight | 150 kg |
Annotation | Illustrations and specifications may vary. The manufacturer reserves the right to replace certain components with components of similar quality. |
Manufacturer Information | FOCUS Bikes GmbH |
