DT-Swiss HX 1501 SPLINE ONE Hybrid Boost rear wheel

DT Swiss - HX 1501 Spline One

This is what e-mountain bikers have been waiting for: The wheels of the HYBRID series are completely designed for the special requirements of electrically assisted MTBs. The newly designed rims have reinforcements in the area of the spoke holes, but could be weight-optimized elsewhere.

The hubs have been reinforced as a whole and can cope with the highest torques without complaint: large dimensions and with higher wall thicknesses, heavy-duty axles, large ball bearings, steel freewheel bodies, 24T toothed discs made of hardened steel, and like the rims with reinforced spoke holes. The minimal additional weight raises the permissible system weight to a proud 150 kg. The HYBRID system is rounded off with specially reinforced Straight Pull spokes and Pro Lock Squorx Pro Head nipples. Tested the new wheelsets in every respect under tougher conditions: with more pull on the spokes, more torque, more load, more life cycles.

The HX 1501 SPLINE ONE wheelset is at home in every scenario: from endless gravel climbs to flowy trails with lots of benders to adventurous, rough terrain. Rugged, lightweight and available in a variety of rim widths, the HX 1501 SPLINE ONE is ready for anything. With its optimal combination of lightweight construction and robustness, every e-mountain biker will find their flow.

Details

• Material: aluminum
• Axle standard: HR 12/148 mm TA
• Hub: Based on SPLINE 240s with 24T ratchet freewheel. Steel body for Shimano
• Brake mount: IS 6-hole
• Rim: HYBRID system specific, aluminum, welded, clincher tubeless-ready
• Dimension: 584 x 35 mm
• Spokes: HYBRID-system specific, Straight Pull, black
• Nipple: DT Pro Lock Squorx, aluminum, silver
• Lacing: 28 x 3-cross
• Max. System weight according to manufacturer: 150 kg
• Included: Tubeless-ready rim tape, tubeless valve. Only HR: 12 mm Sram MTB XD 11/12 Kit.
