CUBE Trike Hybrid Family 1500 (2024)

Item no. 69093
7,999.00 € *
[1]
Variant
Size
The future is here, it's actually pretty neat, and we're not just talking about the unique tilt mechanism. With its twin battery providing 1500Wh of juice to the Bosch drive system, this easy-to-ride people (and cargo) carrier means you can leave the car at home and still arrive at your destination fresh and relaxed.

Highlights

Lighting

ACID Front Light PRO-E (110 Lux)

Frame

Aluminium

Fork

SR Suntour MOBIE 34 CARGO (100mm)

Shifter

Enviolo Cargo manual

Brakes

Tektro Auriga Twin+ (180/160)

Drive Unit

Bosch Cargo Gen4 (85Nm) / PowerTube (1500Wh)

CUBE Trike Hybrid Family 1500

Humans need to move, but it's becoming clearer that cars can be a problem rather than a solution. The Trike Family Hybrid 1500 offers a refreshing, practical and easy-to-ride alternative. An innovative design in its own right, it harnesses the power of Bosch's fourth-generation CX Line drive system with two 750Wh batteries for a total of 1500Wh. There's a Suntour Mobie34 suspension fork for a comfortable ride, even on rough city streets. We fitted powerful disc brakes – and a parking brake – to keep you safe in all weathers, and the stepless hub gear makes light work of any journey. The clever one-size-fits-most design uses a telescopic seatpost and an adjustable handlebar. At the rear, the versatile cargo box with built-in (but removeable) seats, safety harnesses and rain cover makes it a cinch to take along your kids, the shopping, the recycling... whatever you need. And the unique tilt mechanism, combined with the stability of three wheels, means it's as easy to manoeuvre as any normal hybrid bike. Who needs a car?

Frame details

A CUBE design concept powered by Bosch, the Trike Family Hybrid 1500 will redefine your expectations of pedal-powered transport by combining bicycle-like handling with the stabilty and safety of three wheels. Fourth generation Bosch CX Line drive is powered by twin 750Wh batteries, for a total of 1500Wh – meaning extended range. The unique tilting mechanism de-couples the load at the rear from the bike at the front, giving a natural feel to cornering. At the rear, the lightweight and tough box is designed with a high back and sides to help protect your children. A built-in rain cover lifts on its own gas strut, and the versatile seating and safety harnesses can be quickly and easily stowed away if you want to carry a cargo load instead. There's even a storage compartment in the main frame, and the option to fit a front rack. Now... do you really need to take the car?

Additional Information

Bike category Cargo Bike
Brand Cube
Model year 2024
Colour blue´n´reflex
Weight 75 kg
Wheel Size 20'', 24''
Frame Aluminium Gravity Casting, Comfort Ride Geometry, Tilting Technology, Downtube Storage
Frame type Cargo Bike
Fork SR Suntour MOBIE 34 CARGO 24", 100mm
Customization - only in store
Rims CUBE EX40, 507 x 36H / 406 x 32H, DISC, Tubeless Ready
Cassette KMC 3mm, 18T
Front hub Cube Cargo Hub, 36H, Straightpull, 110x15mm Boost
Rear hub Cube Trike Hub, Straightpull
Front tire Schwalbe Pick-Up, Super Defense, 65-507
Rear tire Schwalbe Pick-Up, Super Defense, 65-406
Shifters Enviolo Cargo manual
Crank ACID E-Crank, 170mm, 42T
Chain KMC e101 EPT
E-Engine Bosch Drive Unit Cargo Line Generation 4 (85Nm) Cruise (250Watt), Smart System
Battery pack Bosch Bosch PowerTube 750 Axial + Bosch PowerTube 750 Axial
Display Bosch Kiox 300
Remote Bosch LED Remote
Charger Bosch 4A
Brake Tektro Auriga Twin+ HD-E745 with parking lock mechanism (180/160)
Handlebar CUBE Comfort Trail Bar, 700mm
Bell Ring Bell
Grips ACID Travel Comfort Gripshift
Stem Cube Comfort Stem Pro, 31.8mm, Adjustable
Headset ACROS Carrier Mount Headset
Saddle Natural Fit Sequence Comfort
Seatpost Satori Sorata 34,9mm, 280mm -440mm telescoping seatpost
Headlight ACID Front Light PRO-E 110, 5-16V, DC
Back light Supernova T-M99
Mudguards ACID 75
Bike stand Ursus XXS
Annotation The illustration may differ. The manufacturer reserves the right to replace certain components with components of equivalent quality.
