Aluminium
Carbon
Vittoria Terreno Dry, 700 x 37c (tubeless)
WTB ST i23 TCS 28"
Shimano GRX 400 (2x10)
Shimano GRX 400 (160/160)
The Cannondale Topstone gravel bikes are developed directly in the cradle of gravel sports in the USA. On the trails of Connecticut, you meet gravel bikers today almost as often as mountain bikers. And with its completely redesigned frame, the 2022 Topstone series further blurs the lines between the genres. Never has a gravel bike been more versatile. Today cruising at speed over a flow trail, tomorrow start with small luggage to the weekend tour. The biggest update has been to the frame, where the rear triangle is now lower on the seat tube. This design improves the vertical damping characteristics of the frame triangle. An important factor, because on a gravel bike it is mainly the frame and tires that determine comfort. Ideal: the rear triangle and fork accept tires up to 45 millimeters wide. Another secret of a good gravel bike is its geometry. On the Topstone you sit upright enough for superior control, and sporty enough to really make speed. With the new Topstone, you're also ready for any bikepacking adventure. The frame offers mounting points for three water bottles and for a top tube bag. But that's not all: the newly developed carbon fork is equipped with threaded eyelets for lowrider front bags.
Already at the founding of the manufacture in the 1970s, Cannondale was one of the first manufacturers in the world to use aluminum in frame construction. A unique know-how, on which until today numerous pro teams trust, both in road and MTB racing. The Topstone impresses with a superior processed frame, which has many features of the top series. Internal train guides protect against dirt and emphasize the tidy design. In version 2, the Topstone comes with GRX 400 components from market leader Shimano. The drive with 2 x 10 shifting and the hydraulic disc brakes were developed specifically for use on rough gravel roads. Other parts such as handlebars, stem and seatpost Cannondale already develops for years in their own laboratories. The competition-ready wheelset with Formula hubs and WTB rims is prepared for tubeless operation.
Bike category | Gravel Bike |
---|---|
Brand | Cannondale |
Colour | Midnight Blue |
Model year | 2023, 2024 |
Wheel Size | 28'' |
Frame | Lightweight SmartForm C2 Alloy, 12x142 thru-axle, tapered headtube, BSA threaded BBm flat mount disc, StraightShot internal cable routing, multiple gear/bottle mounts |
Frame type | Diamond |
Fork | Topstone Carbon, 1-1/8" to 1.5" steerer, 55mm OutFront offset, flat mount disc, internal routing, 12x100 thru-axle, fender/gear mounts |
Customization - only in store | Anpassen der optimalen Sitzposition entsprechend deiner Anatomie |
Rims | WTB ST i23 TCS, 28h, tubeless ready (tubeless/schlauchlos) |
Hubs | (F) Formula cartridge bearing, 12x100mm centerlock / (R) Formula cartridge bearing, 12x142mm centerlock |
Tires | Vittoria Terreno Dry, 700 x 37c |
Shift / brake unit | Shimano GRX 400, 10-speed |
Front derailleur | Shimano GRX 400, braze-on |
Rear derailleur | Shimano GRX 400, Shadow RD+ |
Crank | FSA Omega AGX+ Alloy, 46/30 |
Cassette | Shimano HG500, 11-34, 10-speed |
Chain rings | 46/30t |
Chain | KMC X10, 10-speed |
Brake | Shimano GRX 400 hydraulic disc, 160/160mm RT54 rotors |
Handlebar | Cannondale 3, butted 6061 Alloy, 16 deg flare drop |
Grips | Cannondale Bar Tape, 3.5mm |
Stem | Cannondale 3, 6061 Alloy, 31.8, 7° |
Headset | Integrated, 1-1/8" - 1-1/2" |
Saddle | Fizik Aliante Delta, S-alloy rails |
Seatpost | Cannondale 3, 6061 Alloy, 27.2 x 350mm |
Annotation | The illustration may differ. The manufacturer reserves the right to replace certain components with components of equivalent quality. |
Manufacturer Information | Cycling Sports Group Europe B.V. |
